Signers Xuperb EZ-805

Signers Xuperb EZ- 805

Signers Xuperb EZ-805 Overview

• Clear Images (focal spot : 0.8mm)
• Light weight, perfect portable (3.8kg with Battery)
• Amazing performance (80kV /5mA)
• More than 100 shots with full charge battery
• Able to shot X-ray even while charging
• Clear collimator beam
• Laser SID measurement

• X-ray Generator	Type Power Output	MEDICAL 400 W
  X-ray Performance	Tube Voltage Tube Current	50 ~ 80 kV (1 kV step) 2 ~ 5 mA (1 mA step)
  X-ray Control	Exposure Time Set	Time : 0.03 ~ 2,00 sec 0.03 ~ 0.20 (10 msec step) 0.20 ~ 2.00 (50 msec step)
  Collimator	SID	SID 100cm / 43cm x 43cm
  X-ray Tube	Anode Type Anode Angle Focal Spot Anode Heat Capacity Max. Anode Cooling Rate Nominal Anode Input Power at 0.1 s (DC)	Stationary 16 Degrees 0.8 mm 8000 J 110 W 1280 W
  Power Requirement	Number of Exposure AC Power Adapter Charging Time of Battery	About more than 100 times at 70 kV, 5 mA, 0.1 secAC 100 ~ 240 V, 50/60 HzAbout 1.5 ~ 2.0 hour
  Weight	Main Body	3.8 kg
  Dimension	Main Body	266 x 260 x 163 mm
